Thursday, December 1, 2016

16-12-01 PHOTOS: North Central Limited

So every year I try to make it out to Chicago and after a 2 year hiatus I would once again be patronizing the Capitol Limited in the process. Unfortunately I would be taking the train in the westbound direction during the month of November, which meant that I was pretty much out of light upon departure from Washington, DC. Further on, light travel closed the rear coach so I lost my other chance at train-based photography. However I was able to patronize the new First Class Lounge at Chicago Union Station and get some photos of the CUS yard complex from Roosevelt Ave while walking to Trader Joes.

The video content from the trip will come in a followup post and consists of a North Central Service express run inbound to Union Station from O'Hare. You can view the full set of photos here.

The engines for my Train 29 that day were Amtrak P42DC's #51 and #133, seen here sitting at the long platform with K Tower at the end.


On the opposite track was MARC MP36PN-3C #16.


As this was the height of the evening rush, a VRE gallery car trainset hauled by VRE MP36PH-3C #V65 made its way from Ivy City to the lower level of Union Station.






Out on the old B&O main line, between the new crossover at MONTROSE and the station stop at Rockville, we had a friendly race with a set of classic style WMATA equipment on the Red Line.


Due to the time of year and the crappy weather I lost light pretty quickly, but I did manage to snage these interesting photos of the Metropolitan Grove and Germantown MARC stations. Come on Germantown, install some LED lighting already!



Skipping ahead to Chicago, Amtrak P42DC's #76 and #67 were both at the Lumber St locomotive shoppes.



P42DC #133 at the end of its run in Chicago Union Station.


Sunday, November 27, 2016

16-11-27 PHOTOS: Thanksgiving at the Airport

One handicap of the Halethorpe Station is the presence of a track fence that somewhat mars the view of trains in the opposing direction. The low level West Baltimore MARC station lacks such a fence, but that station is located on a low speed section of track that makes video coverage bit less exciting. The clear solution to my problem was the Martin State Airport MARC station off I-95 north of the City. Not only is it equipped with low level with duckboard platforms serving all 4 tracks(!), but Amtrak trains pass the station at full speed. There is only limited MARC weekend service outside the daylight hours, but with unobstructed photo angles I figured that the Martin Airport station would be just as strong as a railfan magnet as the Halethorpe Station had been. It would also allow me to catch the second of the Holiday Extra Arrow sets about 30 minutes earlier in the day, which was important this late in the year.

Unfortunately, my prediction turned out to be wildly off the mark as not a single other railfan showed up throughout the 2 hours I was camped out at Martin airport. While things got a little boring from time to time, I did indeed get a number of great photos, although towards the end of the day I had found myself transported to Planet Golden Hour and, unlike director Michael Bay, even I can admit when there is too much of a good thing. End result was I caught both southbound Arrow Holiday Extras, one MARC holiday extra and one Amtrak Regional Extra. You can find the full set of photos here.

First on the scene was Amtrak Train 91, the southbound Silver Starve, pulled by ACS-86 #655. Fortunately I had already purchased my lunch at a nearby IKEA.


Amtrak Acela Express train #2254, with power car #2025, and another southbound AX with power car #2038, show off the ideal lighting available at Martin Airport at that time of year.



Northbound lighting was not so good as seen here with a 10-car Train 96 pulled by ACS-86 #646.


A bit of cloud had drifted in frot of the sun when Amtrak Holiday Extra #1057 rolled by with NJT Arrow III #1392 in the lead.


 Wider angle shot of Weekend AX #2251 with power car #2003.


Unfortunately my luck did not hold out and MARC equipped Holiday Extra #1065 was powered by Amtrak ACS-86 #608 instead of a MARC HHP-8. Still, a 6 car single level train trailed by cab car #7756 was a nice sight in the era of split level coaches.



Golden Hour was in full swing as Holiday Extra train #1099 passed by with NJT Arrow III #1361 leading. Note the crowd of people in the vestibule cab. I also got a nice acknowledgement on the horn.


Wednesday, November 23, 2016

16-11-13 PHOTOS: HOLMES for the Holidays

One of my more enjoyable Thanksgiving traditions involves heading out with Chuchubob om thanksgiving Wednesday to catch the smattering of extra trains and additional cars added to the usual NEC lineup in order to accommodate the increased holiday crowds. In past years we have tended to gravitate towards the Trenton area, photographing the NEC at such locations as Bristol, Levittown and Morrisville and then wandering by West Trenton to top up with some SEPTA and CSX action. This year Bob and I decided to stay a bit closer to home, hopping across Ye Olde Betsy Ross Bridge to the Holmesburg Jct SEPTA station and Amtrak interlocking. This also allowed us to get our quota of freight action wrapped up ahead of time with a quick stop by the Cove Road grade crossing just shy of CP-HATCH at the north end of Pavonia Yard. You can check out the full set of all these photos here.

Acting on one of Bob's tips, we managed to catch rare Blue CN C40-8W #2455 that was coupled ahead of NS C44-9W #9344 on Train 39G.


As we took pictures of 39G, the Pemberton Branch local freight arrived from the yard NS GP38-2's #5278 and #5271 providing the power. Here's a photo of the local power edging up next to NS standard cab SD70 #2559.


 The third track at Cove Rd is for the NJT RiverLINE light rail and with 15-20 minute headways we were on hand to catch #3514A heading southbound.


Three wide at Cove Road!


Moving on to Holmesburg Jct we caught an inbound SEPTA R7 Silverliner V trainset with #716 in the lead.


 Holmesburg Jct is still a junction in the form of HOLMES interlocking, a 4-track full crossover with a connection to a 5th industrial track and the Bussleton Branch. The old HOLMES tower is actually part of the SEPTA station building.


The first interesting sight was the northbound Train 86, hauled by ACS-86 #638, which was sporting an extra Horizon coach.


Next up was Train 51, the westbound Cardinal, running a couple hours late from its initial terminal and pulled by ACS-86 #608.


Of course there were hourly R7 trains in each direction running with extra cars. SL-IV #298 appeared on an eastbound example shown here passing under the HOLMES westbound signal bridge.


There were also hourly Acela runs such as this example bracketed by power cars #2010 and #2015.


Sunday, November 20, 2016

16-11-20 PHOTOS: Reading Line West

The former Conrail Reading Line runs from the west end of Allentown Yard to Wyomissing Jct, just west of Reading, PA. Until now it has been run as a traditional single direction Rule 251 ABS signaled railroad, but ever since the Harrisburg Line between Reading and Harrisburg was converted to bi-directional Rule 261 ~2000 there has been mounting pressure to eliminate the final bastions of 251 operation on one of the busier railroad trunk lines in the east. Prior to Thanksgiving weekend I took a road trip out to Reading country to join friend of the show Kevin Painter for a little informal trip to check out the outgoing signal locations on the eastern part of the Reading Line between Reading and Alburtis, PA. We also caught quite a number of passing NS freight trains running to and from the New York/New Jersey market. You can find the full set of photos here

The Reading Railroad was built to service the anthracite coal fields north of the city and deliver the goods down the river to Philadelphia. However as coal diminished in importance for household heating, Reading focused on other markets including its east-west corridor connecting New York with points west that bypassed the PRR/NYC duopoly in that market. Also, by the 1950's, dieselization meant that east-west through freights did not need to stop for servicing in the Reading terminal area, but the coal age layout was adding unnecessary delays to an increasingly important source of traffic. The solution was a new single track "low grade" line that linked the junction of the Reading Belt Line and Main Line (Belt Jct) north of Reading with the original East Penn line to Allentown at Blandon. Not only did the new track bypass the congested terminal, it did, as the name implies, decrease the ruling grade from 1.1% to 0.6%. The old route, now called the Hill Track, declined in importance and was ultimately ripped out in 1989.

The Low Grade line went along with a state of the art signaling scheme provided by General Railway Signal. Minor interlockings in the Reading area were put under the remote control of two towers, OLEY and VALLEY JCT. Of course both of those towers were eventually remote controlled themselves around 1990 and then most of the territory they controlled were re-signaled in the waning years of Conrail. However, the short stretch of Low Grade Line between CP-BELT and CP-BLANDON remained untouched until today. Here we see a clear signal indication for the Main track at CP-WEST LAUREL, which marks the end of a short siding between here and CP-BELT. The signals are GRS originals from the 1950's as is the poured concrete relay hut.


The signal was for an eastbound doublestack intermodal train that I caught at the Tuckerton Rd crossing within the limits of CP-LAUREL just about a mile east of CP-WEST LAUREL. That train was led by a trio of NS C44-9W's including #9276, #9612 and #8916.



CP-LAUREL is the home of the former Reading Temple Station, which is the once and future terminus of the Reading and Northern's Berks County passenger service. Today the station area hosts an R&N SW8 switcher as well as a number of former Reading RR coaches purchased from SEPTA including former Reading MU car #9103..



Soon after an Approach Limited signal popped up on the eastbound 330L signal, which was soon followed by a TOFC intermodal train hauled by NS C44-9W #9826, C44-10W #7654 and SD70ACe #1154.




You can really tell this interlocking is original 1950's equipment by looking at the concrete relay hut with above ground, cotton insulated cabling strung out to the remote locations. If you look at the signal charts the switches and signals are still numbered in accordance to the old interlocking machine OLEY tower.


Here we see NS SD60E #7006 passing the 330R signal with a westbound merchandise freight.


Three back in the lashup was UP SD70M #3895.


The 330R signal immediately displayed an Approach indication, but nothing was forthcoming and I decided to move on. Note the Reading style sideways mounted bottom head used for restricting indications. Also, there exists a short 1 mile signal block between CP-LAUREL and CP-WEST LAUREL immediately after a long descending grade. This is one of those locations that keeps crews on their toes.




CP-BLANDON is the junction where the east end of the low grade line split off from the Hill Track. With coal region traffic pretty much dead by the 1980's Conrail developed a plan to re-organize the east-west traffic patterns for eastbound trains to use the Low Grade Line and westbounds the Hill Track. Of course this would force traffic to cross at both ends of the route as well as clearance improvements through the Reading yard complex so ultimately Conrail accepted the single track bottleneck on the Low Grade route and took the Hill Track out of service in 1983. Ironically, the route was temporarily returned to service in early 1984 when part of the Low Grade line fell into a quarry south of CP-WEST LAUREL, however by 1989 determined that the excess capacity was no longer needed and lifted the rails. Here we can see another pair of NS C44-9W's, #9528 and #9068, hauling an eastbound merchandise freight and if you look carefully you can still see where the Hill Track right of way diverged.


Sunday, October 30, 2016

16-10-30 VIDEOS: Autumn Express - Amtrak Harrisburg Line

Rear vestibule access on the Autumn Express didn't just mean I could take great pictures out the back, I could also shoot video. In fact, thanks to my GoPro, I could do both at the same time. Although the NS freight route was the rare mileage, I saved my limited battery and memory card capacity for the faster / more exciting eastbound Amtrak Harrisburg Line run, including the NY->Pittsburgh subway. While in theory this line does have a railfan view from the Metroliner Cab Cars, the Autumn express run would be, well, express, and who can say no to that.

We begin with our departure from the former PRR Harrisburg Station. With me in the vestibule was an older gentleman and a kid, both railfans and sources of interesting commentary. This video includes a segment of wrong railing between STATE and ROY, where we return to track #1 to pass train 43, the westbound Pennsylvanian. We then proceed to RHEEMS interlocking where we cross back over to track #2.



Now because the eastbound Pennsylvanian and a westbound Keystone needing to do their thing at Lancaster before we tied up the platform, we were put on track to and then ran at reduced speed in order to kill time. I had gone to take a nap then returned to see the train moving at Restricted speed. At the time I assumed it was a signal problem, but actually they wisely wanted to keep the foliage train moving, even at a crawl, to avoid having the lookie lous stare at the same tree for half an hour.



After the easily amused railfans got their faux arrival photos at Lancaster, we departed and proceeded to run express all the way to Newark, New Jersey. This video just captures the part through to Downingtown where I cut it to change batteries in order to get the old PRR Main Line without a disruption. Note the new PARK interlocking, the old PARK tower and the still active THORN tower. Also note the closed Irishtown Rd crossing because stimulus money.



Now this video is something special. Like I said in the previous post, because of work in BRWN MAWR interlocking, our train was routed on Track 3 eastbound through PAOLI interlocking and then on to OVERBROOK. Not only are reverse movements on Main Line track #3 (the only Rule 261 track) uncommon, but since this video was taken, both tracks 2 and 3 through Paoli station were cut and removed to make way for an island platform :-( Also included in this video is the trip through the NY-Pittsburgh Subway (although that was also included as a stand-alone in the previous post).



Because of the catastrophic backlighting, I basically gave up on video and photos after we joined the NEC. I had previously shot GoPro video on the route and didn't see a need for another, worse edition. However I did get one short segment capturing SHORE interlocking and the Frankford Jct curve.



Well I hope you enjoyed my little rare millage trek across PA. Tune in next week as I return to the NS Reading line for some close up photos with friend of Subchat, Kevin Painter.

16-10-30 PHOTOS: Autumn Express - Amtrak Harrisburg Line

The final part of my trip on Amtrak's 2016 Autumn Express will cover Amtrak's Harrisburg Line, aka the former Pennsylvania Railroad Main Line between Philadelphia and Harrisburg. Amtrak would use the old PRR route to return the Autumn Express to New York City and with speeds up to 110mph the travel time would be a fraction of what it took to get out on the overall shorter freight route. Because of the faster travel time, Amtrak was able to schedule a special photo stop at Lancaster to allow the passengers to get out and take photos of the giant Autumn Express trainset as it backed up and then made a repeat arrival. After that it continued on to Philly, utilizing the famous New York->Pittsburgh Subway to access the westbound NEC. Unfortunately a North Philadelphia stop was not provided for those passengers needing to return to the philly area or points south.

You can find the photos from this section of the trip here, just scroll down about half way until you see the Harrisburg Station.

 The Harrisburg Station complex had recently been rebuilt with a new layout, new signaling and concrete ties on all the station tracks. Here we see the catenary inspection car sitting on track 5, just behind the PRR caboose and GG1 #4859 that are on display under the Harrisburg trainshed.


Departing through the new, simplified STATE interlocking. In addition to the tower being closed, parallel routes were eliminated and others were raised to 30mph from 15mph. Track 8 was also eliminated as a through track leaving track 4 as the only other through track aside from the high level platform tracks 6 and 7. This was likely necessary to support wide freight and equipment movements.





Here we see the graceful curve leading up to the Royalton flyover that allows the old log grade freight tracks to relocate to the west side of the right of way in order to branch off towards Columbia, PA. Located at the end of Harrisburg International Airport's single runway, the hulk of a a Convair VT-29B Samaritan used for fire training can be seen in the background.


After crossing over at ROY interlocking, we met Amtrak P42DC #96 with the westbound Train 43, Pennsylvanian waiting for its turn to proceed.


This squat structure is actually the old PRR LANDIS interlocking tower in Landisville, PA. A small table type interlocking machine installed controlled a diamond crossing with the Reading Company's Columbia branch. Long removed, it was one of the few at grade diamond crossings on the eastern part of the PRR Main Line.


Because we were running early and due to platform availability issues at Lancaster, we had to wait for both the eastbound Pennsylvanian and a westbound Keystone to pass before we were able to proceed through CORK interlocking. Train 42 was being hauled by P42DC #97 and the Keystone was being trailed by Metroliner cab car #9638.



16-10-30b PHOTOS: Autumn Express - NS Harrisburg Line

So the final "rare mileage" part of the 2016 Autumn Express was run over the NS Harrisburg Line between CP-WYOMISSING JCT, just west of Reading and CP-CAPITOL in Harrisburg. Of course this segment of track had been trodden before by the 2014 Autumn Express, that actually came and went over the route in both directions. Of course this year I was able to take photos out hr back whereas before I was not. You can find the full series of photos at the top of this photo set here.

After running up the ramp from the Reading Line, out train entered the Harrisburg Line at CP-WYOMISSING JCT. The Harrisburg Line between Reading and Harrisburg had been run under Rule 251 ABS up through the Conrail era, but a CTC project was one of the first orders of business for NS due to the 40-50 trains a day that traversed the line to serve both the New York and Philadelphia markets.


Although not as well known as the Reading Main Line between Philadelphia and Reading, the old Lebanon Valley Branch, as it was called, boasted a lot of Reading station infrastructure for both New York and Philly bound passenger services. Here we see old Reading stations in Wernersville and Lebanon.



 After crossing over at CP-DORF, we passed an eastbound merchandise train with a trio of NS locomotives including former Conrail C40-8W #8396 and a 5000 series SD40-2, and one unidentified Reading and Northern EMD.


The Penn Supply Milard quarry has a small fleet of ex-road power to shift the long aggregate trains through its loading facility. Here we see long time power B23-7 #250 and SD40M-3 #6521 along with a newly acquired ex-UP SD40.


A short distance away in the receiving yard was NS C40-9W #8865 and SD60E #6916. Both classes are common in the Harrisburg area.


In Palmyra, a cut of cars was being prepared for set-out by some road power including NS C44-9W #9519 and SD60 #6707. Note the osage oranges all over the track.



NS GP38-2 #5303 was working the Hershey yard with a former Conrail cabin car. As you might surmise, the Hershey yard mostly supports operations for the Hershey company that has many plants in and around the Hershey, PA area.
